Laser Marker Y.0201-DN
Fiber laser marker
Day-Night-Design

Forward-thinking technology for backlit components: The new standard for high-speed, high-precision day & night marking (paint removal)

Send Product Request

Overview

Day & night design of painted controls as well as backlit dashboards and buttons requires fast, high-quality and high-precision marking (paint removal). Over the past 25 years, FOBA has established itself as a preferred marking solution for global manufacturers and automotive suppliers. FOBA lasers apply functional marks that convince on various colors, coatings and materials with their utmost black-white brilliance or superior light-dark contrast.

These proven solutions are now being enhanced by a new day & night marking laser especially tailored for demanding paint removal applications: The Y.0201-DN comes with an integrated vision system for increased precision and up to 80 percent less scrap due to marking, and with up to 50 percent shorter process times.* This makes the new high-precision fiber laser marker the new benchmark for the repeatable layered color and paint removal. The marking results are of superior quality, and users can rely on the low operating costs and extra productivity the system ensures.

*compared to similar products on the market


Benefits

Exact paint removal

Highest efficiency

Precise and high contrast

Superior marking quality at 50 percent higher* marking speed + More throughput due to larger marking field + Enhanced application range due to smaller spot size and optimized beam quality (finest, highly precise removal, sharp contours, no melting)



Mark economically

Low operating costs thanks to 8 times longer lifetime of laser source** + High uptime due to efficient and low maintenance air cooling, improved beam stability, resistance against critical environmental conditions (i.e. high temperatures) and dust-tight IP64 laser head

Fast set up

Shortest set up with Autofocus in the M-Series workstations (3 times faster vs. manual focus finding) and due to intelligent software features (Parameter Matrix Tool, contour offset, mark alignment, etc.)




FOBA Day & Night Solutions High Contrast for Optimum Visibility in Daytime
and Brilliant Illumination at Night


Application


Technical specifications

Y.0201-DN

Y.0201-DN

Technical specifications
Marking head SS10 with high-precision focusing optic (f = 420 mm)
Marking field* 290 x 290 mm2
Marking speed* Up to 20,000 mm/sec., up to 800 characters/sec.
Laser source
Type Pulsed Ytterbium fiber laser (Yb), 20W, several selectable pulse durations from 4 to 200 ns, wavelength 1064 nm
Laser class 4 (acc. to IEC 60825-1)
Interfaces
  • PC software FOBA MarkUS and FOBA Draw (on separate, external, optional Windows 7 or Windows 10 PC**)
  • TCP/IP, Profibus, Profinet (optional)
Supply
Electrical requirements L/N/PE 1 – 240 VAC, 50/60 Hz
Power consumption 400 VA
IP rating
  • Marking unit IP64
  • Supply unit IP21
Cooling Air-cooled, auto overheat protection
Temperature 5 - 40° C
Humidity 10 - 90 %, non-condensing
Weight
  • Marking unit approx. 10 kg
  • Supply unit approx. 19 kg
Scope of delivery, options and accessories
Scope of delivery
  • Fiber laser marker
Options, accessories
  • IMP camera for mark alignment andvalidation (integrated in marking head)
  • Lighting for camera systems IMP, Point & Shoot
  • Rotating units (with M-Series)
  • Customer specific plugins
  • Exhaust systems
Machine integration
  • M2000/3000-B (workstations with worktable and programmable Z-axis)
  • M2000/3000-P (workstations with programmable axes X, Y, Z)
  • M2000/3000-R (workstations with 2-station rotary table and programmable Z-axis)



*Depends on the application ** with MarkUS version 2.12 as of Q2 2018
